Item:
Details:
Product: SMA Fiber Optic Connector
Model NO.:SMA Fiber Optic Connector
Introduction:
SMA Connector is a Fiber optic Connector developed by Amphenol Fiber Optic Products,SMA stands for SubMiniature version A. SMA connectors use a threaded plug and socket.The SMA connector holds a single fiber.SMA connectors have a threaded Coupling nut. The Ferrule is traditionally made of steel, although ceramic versions are available.
Features:
1.Low insertion loss
2. High return loss
3. Low IL / RL loss
4. Compact size and light weight
5. Bellcord GR-326 conformed
6. SMA, D4, DIN and ESON / FDDI available
Applications:
1. Telecom network
2. Industry communication
3. Military communication
4. FTTH
5. CATV
Specifications:
Item
Multi mode
Insertion loss
PC<0.3dB
Return loss
PC>35dB
Insert-pull test
1000times<0.2dB
Operating temperature
-40℃ ~ +80℃
Ceramic ferrule spec
127um concentricity deviations:<3um
Suitable fiber
PC (50/125um ,62.5/125um)
Ordering Information:
–Supply SM,MM, simplex connectors.
–Supply all set connectors and accessories(SKD)
–Supply 3.0mm ,2.0mm ,0.9mm boot.
To meet customers’ various requirements, we offer various types of SMA902 and SMA906 fiber optic connectors, of which the body materi
