JTCV-750-14 multi-cores side glow fiber optic lighting

Get A Quote

Main Features

Item:JTCV-750-14
Details:
Multi-cores Side Glow Fiber Optic Lighting Cable
Fiber optic side glow cable
Fiber Optic Side Glow cable is a new and green lighting product, which is a safe alternative to neon. By using with various light sources such as LED light source, Metal Halide light source, Halogen light source etc., fiber optic lighting has following advantages:

1. Color changing, which is virtually unbreakable and energy efficient;

2. Suitable for interior and exterior applications. It is UV protected, which has an algaecide and fungicide treated exterior jacket for maximum durability against the elements.

3. Side Glow fiber optic cable is strong enough for amusement park rides, extreme cold weather as well as underwater applications. With no heat or electricity in the cable, it is safer compared with typical lighting design restrictions.

Applications

1. Interior lighting decoration of KTV , pubs , coffee houses , hotels and restaurants;

2. Artistic adornment in graphical and 3D artistic design;

3. Lighting in swimming pools and underwater facilities;

4. Large-size backdrop of lighting waterfall.

Basic properties



Jacket material



Transparent , anti-ultraviolet PVC



Numerical aperture



0.5



Allowable bend radius



10 times larger than fiber core diameter



Using temperature range of the cable



-40~+85



Model specifications



Model



Core strands



fiber/cable diameter (mm)



fiber core material



JTCV4-750-14



14



0.75/6.0



Polymethyl methacrylate / Fluoresin



JTCV4-750-42



42



0.75/10.0



JTCV4-750-84



84



0.75/14.0



JTCV4-750-126



126



0.75/18.0
