FC Fiber Optic Patch Cord

Get A Quote

Main Features

FC fiber optic patch cord is also called FC fiber optic patch cable, which is one of the earliest type and one of the most commonly used fiber optic cable.

Advantages of FC fiber optic patch cord:
it is convenient to use and cost saving,
It is the most cheapest type fiber optic patch cable.

FC fiber optic patch cable is widely uesed in fiber optic networks. FC fiber patch cable is with zirconia sleeve and plastic housing. The FC APC fiber optic patch cord
is available in both singlemode and multimode versions, and is fully intermateable with NTT-FC products. Both singlemode and multimode versions FC fiber patch come with a zirconia ceramic ferrule with pre-polished PC profile and convex spherical end. These endface types allow for faster polishing, and low back reflection and optical loss,while ensuring maximum
repeatability.

FC Fiber Optic Patch Cord Features:

♦ Low insertion loss.
♦ High return loss.
♦ High stability and reliability.

♦ General use waterproof, adapt for hard outdoor environment

♦ Easy to install,high reliability

♦ 2,4,6 cores available

FC Fiber Optic Patch Cord Applications:

♦ FTTH, LAN, PON & Optical CATV
♦ Local ring net
♦ Optical fiber communication system
♦ Optical fiber test equipment
♦ Optical fiber sensor or fiber optic sensor

FC Fiber Optic Connector Specifications:

Item Single mode Multi mode
Fiber diameter 9/125um 62.5/125um 50/125um
Insertion loss PC<0.3dB  APC<0.2dB PC<0.3 dB
Return loss PC>45 dB  APC>60 dB PC>25 dB
Insert–pull test (1000 times)<0.3 dB
Interchange <0.2 dB
Operation temperature -40℃ ~ +80℃
Anti-tensile force 15kgf

We offer single mode and mutlimode FC fiber optic patch cables like SC-LC, SC-ST, SC-FC, SC-MU, SC-MTRJ, SC-E2000 etc.custom design SC fiber optic cable assemblies, 9/125μm, 50/125μm, 62.5/125μm, SM, MM, simplex, duplex.
